Title
Digital Indicator DIN878 0–50.8mm | 0.01mm / 0.001mm Resolution Electronic Dial Gauge Manufacturer Supplier
Description
Digital Indicator is a precision measuring tool designed for displacement measurement, dimensional inspection, and tolerance analysis. It offers a measuring range of 0–50.8mm (0–2") with 0.01mm / 0.001mm resolution and integrated data output, making it suitable for machining, automotive, electronics, and precision engineering industries. Manufactured with a reinforced housing and anodized aluminum back cover, this tool provides stable, repeatable, and efficient measurement for inspection, machining, and quality control applications.
SKU Table
| Model / Art No | Range | Accuracy | Resolution |
|---|---|---|---|
| 12-3116-145 | 0–12.7mm (0–0.5") | ±0.015mm | 0.01mm |
| 12-3116-245 | 0–25.4mm (0–1") | ±0.018mm | 0.01mm |
| 12-3111-423 | 0–50.8mm (0–2") | ±0.020mm | 0.01mm |
| 12-3116-121 | 0–12.7mm (0–0.5") | ±0.005mm | 0.001mm |
Technical Specifications
- Product Name: Digital Indicator
- Category: Electronic Dial Gauge
- Range: 0–12.7mm / 0–25.4mm / 0–50.8mm
- Accuracy: Up to ±0.005mm (high-resolution model)
- Resolution: 0.01mm / 0.001mm
- Material:
- ABS housing (black)
- Anodized aluminum flat back cover
- Display: LCD digital display
- Output: Data output interface
- Structure Feature:
- Three-button control (in/mm, ABS/PRESET, ZERO/ON)
- Flat back design
- Protective cap on measuring spindle
- CE marking and environmental compliance symbol
- Side laser-marked serial number
- Standard: DIN878
- Brand: Neutral (OEM available)
- Model / Art No: 12-3116 / 12-3111 series
Applications
This product is suitable for:
- Linear displacement measurement
- Runout and concentricity inspection
- Machine tool setup and calibration
- Comparative measurement in fixtures
Widely used in:
- Precision machining
- Automotive manufacturing
- Electronics assembly
- Quality control laboratories
Selection Advice
- 0–12.7mm / 0.01mm: Standard inspection and general workshop use
- 0–25.4mm / 0.01mm: Extended travel for general-purpose measurement
- 0–50.8mm / 0.01mm: Long stroke measurement and setup alignment
- 0–12.7mm / 0.001mm: High-precision applications requiring fine resolution
For alternatives:
- For basic cost-effective measurement → mechanical dial indicators
- For compact applications → mini digital indicators
- For automated inspection systems → digital indicators with SPC output
Key Features
- High-contrast LCD display for clear digital reading
- Dual resolution options (0.01mm / 0.001mm)
- Integrated data output for inspection systems
- Durable ABS housing + aluminum back cover
- Multi-function control: ABS preset, zero setting, unit conversion
FAQ
1. What is the difference between models?
Models differ by measuring range and resolution. The 0.001mm version offers higher precision for fine inspection, while larger ranges are suited for longer travel measurements.
2. Accuracy vs Resolution?
- Resolution: smallest readable increment (0.01mm or 0.001mm)
- Accuracy: allowable deviation from true value (varies by model)
3. Mechanical vs Digital indicator?
- Mechanical: robust, no power required
- Digital: faster reading, no parallax error, supports data output
4. Which industries use digital indicators?
Machining, automotive, electronics, aerospace, and metrology labs.
5. Is customization available?
Yes. OEM services include:
- Logo printing
- Firmware/function customization
- Packaging design
- Barcode and labeling
