IP65 digital outside micrometer
10-03-11
Product Details
IP65 Digital Outside Micrometer 0–300mm | DIN863 Waterproof Micrometer Manufacturer Supplier
Description
IP65 Digital Outside Micrometer is a precision measuring tool designed for accurate external dimension measurement in demanding industrial environments. It offers a measuring range from 0–25mm up to 275–300mm, high-resolution digital reading, and IP65 protection against dust and water, making it suitable for machining, metalworking, and quality inspection applications. Manufactured according to DIN863 standard with a durable painted frame and metal ratchet stop, this micrometer ensures reliable performance in workshop and production environments.
SKU
| Model / Art No | Range | Accuracy | Resolution |
|---|---|---|---|
| 11-3521-141 | 0–25mm | Not specified | 0.001mm |
| 11-3521-227 | 25–50mm | Not specified | 0.001mm |
| 11-3521-327 | 50–75mm | Not specified | 0.001mm |
| 11-3521-427 | 75–100mm | Not specified | 0.001mm |
| 11-3521-523 | 100–125mm | Not specified | 0.001mm |
| 11-3521-623 | 125–150mm | Not specified | 0.001mm |
| 11-3521-723 | 150–175mm | Not specified | 0.001mm |
| 11-3521-725 | 175–200mm | Not specified | 0.001mm |
| 11-3521-827 | 200–225mm | Not specified | 0.001mm |
| 11-3521-824 | 225–250mm | Not specified | 0.001mm |
| 11-3521-823 | 250–275mm | Not specified | 0.001mm |
| 11-3521-821 | 275–300mm | Not specified | 0.001mm |
Technical Specifications
- Product Name: IP65 Digital Outside Micrometer
- Category: Digital Micrometer
- Range: 0–300mm (multiple models)
- Accuracy: Not specified
- Resolution: 0.001mm
- Material: Metal Frame with Painted Finish
- Display: Digital LCD
- Output: None
- Structure Feature: Type B frame, metal ratchet stop, 0.5mm spindle pitch, two-button operation, engraved scale on thimble
- Standard: DIN863
- Brand: Customizable (OEM Available)
- Model / Art No: 11-3521 series
Applications
This product is suitable for measuring external dimensions of shafts, rods, precision components, and mechanical parts. It is widely used in machining, metalworking, industrial manufacturing, equipment maintenance, and quality inspection environments.
Selection Advice
This micrometer series is recommended for users who require high-precision measurement with 0.001mm resolution and reliable performance in harsh environments. Choose smaller range models (0–25mm, 25–50mm) for fine precision parts, and larger range models (100–300mm) for larger components. For basic workshop applications, consider mechanical micrometers. For environments requiring dust and water resistance, this IP65 digital model is the preferred choice.
Key Features
- IP65 protection against dust and water for harsh working environments
- High-resolution digital display with clear and fast reading
- Metal ratchet stop ensures constant measuring force
- 0.5mm spindle pitch for quick and efficient measurement
- OEM customization available for branding and labeling
FAQ
What is the difference between the different measuring ranges?
Each model covers a specific measurement range from 0–25mm up to 275–300mm. Users should select the appropriate range based on the size of the workpiece to ensure accuracy and usability.
What is the difference between accuracy and resolution?
Resolution refers to the smallest increment displayed (0.001mm), while accuracy indicates how close the measurement is to the true value. Accuracy depends on calibration and manufacturing standards.
Is this a manual or digital micrometer?
This is a digital micrometer with an LCD display, allowing faster and more convenient reading compared to manual micrometers.
What industries use this product?
It is widely used in machining, metalworking, manufacturing, maintenance, and industrial inspection where high precision is required.
Is customization available?
Yes. This product supports OEM customization, including customer logo, labeling, and packaging, depending on order requirements.
